Rod tail：R32,R38,T38
Distance from machine top to machine center ：88mm
Impact power：20kW
Impact frequency：42-50Hz
It is used for rock drilling and medium and deep hole drilling. The drilling range is 38~76 mm.
Features
High production efficiency ,low operation cost
High-efficient hydraulic dual-buffer system improves production efficiency and protects the drilling tools and rock drills ,the maintenance intervals up to 600h,which greatly reduces operation cost.
Driving head with independent lubrication to improve production
Driving head with independent lubrication,pressure oil film lubricates each mating surface and side bolt technology improve production efficiency and reduce shutdown time.
Strong power
Motor is powerful and stepless variable,and has two-way rotation，high torque and excellent speed control.
Parameter
| Item | Data | |
| Whole machine | ||
| Size | mm | L1215×W255×H223 |
| Weight | Kg | 170 |
| Distance from top to center | mm | 88 |
| Shank | T38/R38/R32 | |
| Drilling hole diameter | mm | 33~76 |
| Impact property | ||
| Max.Impact power | Kw | 18 |
| Max.Impact pressure | Bar | 230 |
| Impact frequency | Hz | 45~60 |
| Flow rate | L/min | 75~95 |
| Impact energy | J | 300 |
| Rotation property | ||
| Displacement（Standard） | CC | 160 |
| Max.Torque | N.m | 800 |
| Flow rate | L/min | 75 |
| Max.Intake pressure | bar | 210 |
| Rotation speed | Rpm | 0~340 |
| Lubricating air flow rate | L/S | 5 |
| Lubricating air pressure | bar | 2 |
| Water pressure | bar | 25 |
| Water flow rate | L/min | 40~120 |
| Noise level | dB | ≤106 |
| First maintenance time of wearing parts | h | ≥400 |
| Life of impact piston | Linear meter | ≥3000 |
| Packing size | mm | 1235×345×395 |
| G.W. | Kg | 183.7 |
