Rebar Straightening and Cutting Machine

GL4-12

Straightening diameter range: Ф4-12mm
Traction speed: 45m/min, 48m/min
Fixed length: 300-9000mm(can be lengthed)
Cutting length tolerance: ±10mm

Applied Range

Mainly used for straightening and cutting to length, suitable for

cold-rolled grade III steel bars,
cold-rolled round steel bars for construction,
and adjustable straight hot-rolled round steel bars.

Features

High automation and good safety

Simple operation and high production efficiency

The error is small,minimum material loss

Suitable for processing different types of steel bars

Machined Shape

GL4-12

Rebar Straightening and Cutting Machine

Model	GL4-12	Straightening degree	±2mm/m
Straightening diameter range	Φ4-Φ12mm	Traction motor power	7.5KW-level 4
Traction speed	48m/min	Oil pump motor power	5.5KW
Fixed length	300-9000mm	Machine weight	850kg
Cutting length tolerance	±10mm	Dimension	L2200×W730×H1150mm

GL6-14A

Rebar Straightening and Cutting Machine

Model	GL6-14A	Straightening degree	±2mm/m
Straightening diameter range	Φ6-Φ14mm	Traction motor power	7.5KW-level 4
Traction speed	45m/min	Oil pump motor power	5.5KW-level 4
Fixed length	300-9000mm	Machine weight	1100kg
Cutting length tolerance	±10mm	Dimension	L2200×W730×H1150mm

GL4-16A

CNC Hydraulic Bar Straightening and Cutting Machine

Straightening diameter range	Φ4-Φ16mm	Straightening degree	±2mm/m
Traction speed	45m/min	Rated power	27.5KW
Fixed length	300-9000mm	Machine weight	1300kg
Cutting length tolerance	±10mm	Dimension	L2900×W1150×H750mm

Owns the "Geng Li" trademark.

Gengli Machinery

Henan Gengli Engineering Equipment Co Ltd. is a high and new tech enterprise, specialized in R&D, and production of concrete supporting equipment Located in Mengjin, Luoyang it covers an production area of 60000 m2,with the strong independent innovation ability, its product design capability and manufacturing capability is leading in the same domestic industry.

High skilled R&D team
Considerate and fast service
ISO9001 Quality System Certification
