Theoretical output quantity ：3m³/h
Inner diameter of suction pip：φ64mm
Working pressure：2MPa
Maximum delivery distance：Horizontal 120m/Vertical 30m
Used in construction engineering, used for vertical and horizontal transportation of mortar, widely used in grouting and grouting operations of various infrastructure projects and transportation of other media.
Features
Mainly used in constructional engineering
widely used in grouting operations of various foundation construction projects and transmission of other media.
Parameter
Model | GUB |
Production capacity | 5m³/h |
Inner diameter of suction pipe | 64mm |
Working pressure | 2Mpa |
Machine weight | 230kg |
Dimension | 1100×520×800mm |
Maximum delivery distance | Horizontal 120m/Vertical 30m |
Inner diameter of slurry hose | 38mm |
Motor power | 3KW |
Voltage | 380V |
